The Wuxi Jianying DCS/50-A5s Vertical Spiral Bag Packaging Machine is a high-precision intelligent quantitative packaging solution specifically designed for powder and tablet materials prone to dust generation, clumping, or poor flowability, offering standardized 20–50 kg open bag packaging capacity. Widely applicable across industries including new energy, chemicals, metallurgy, food, and pharmaceuticals, it supports common packaging types such as woven bags and paper-plastic composite bags. Leveraging proprietary dynamic weighing algorithms and a modular design, the machine addresses common challenges in traditional packaging systems-including low accuracy, excessive dust generation, material clogging, and complex maintenance procedures. Operable independently or integrated into smart production lines, it represents an optimal choice for enhancing quality and reducing costs in industrial powder packaging. The DCS/50-A5s overcomes limitations of conventional models by delivering four core advantages: broad material compatibility, stable weighing performance, simplified maintenance, and digital connectivity, effectively addressing industry-specific challenges while ensuring robust stability and low overall operating costs, thereby facilitating automated, environmentally friendly, and efficient upgrades in packaging processes.
Technical Specifications
|
Model |
DCS-50/A5s |
|
Range |
20~50kg |
|
Speed |
80 Bag/Hour |
|
Accuracy |
±0.2% |
|
Power Source |
AC380/220/50Hz |
|
Air Pressure |
0.4~0.6 MPa |
|
Air Consumption |
0.3m³/min |
|
Bag |
Plastic bags, paper bags, cardboard boxes, barrels and other forms |
|
Feeding Method |
Vertical Spiral |
Feature And Application
* The core differentiation of the vertical spiral feeding bag packaging machine lies in its superior sealed spiral feeding system, which ensures stable material flow without clogging even for complex materials. Unlike conventional models with standard discharge structures, this equipment features a dedicated vertical sealed spiral forced feeding design specifically tailored for easily adherent or clumping materials such as graphite, lithium iron phosphate, and zinc oxide, delivering uniform and stable discharge while eliminating issues like machine jamming, empty bags, or uneven loading. The fully sealed structure effectively controls dust generation at the source, meeting stringent environmental production requirements in workshops.
* Dynamic adaptive weighing ensures stable accuracy despite operating condition fluctuations. Equipped with a self-developed dynamic weighing compensation system, it dynamically adjusts material feeding allowances in real time and automatically adapts to minor variations in material moisture content and density, eliminating the need for frequent manual calibration. With a measurement range of 20–50 kg, parameters can be switched with a single button press, supporting flexible production across various specifications while maintaining consistently stable weighing precision throughout the process.
* Dust removal system featuring environmental protection and a modular design, with low failure rates and easy maintenance. Equipped with standardized dust collection interfaces that integrate seamlessly with workshop systems for closed-loop dust collection, eliminating leakage and material loss. The compact design occupies minimal space, making it suitable for retrofitting both existing and new production lines. Its modular core components ensure low failure rates, enable rapid disassembly and replacement, significantly reduce downtime and operational costs, and support future capacity upgrades.
* The intelligent data networking system is designed for modern factory management, featuring built-in smart counting and statistical functions to record production volumes and abnormal package counts in real time with traceable production data. It supports industrial communication integration with MES and central control systems, enabling remote parameter adjustment, equipment monitoring, and production data upload, thereby achieving digitalized and refined control of packaging processes.
