The DCS-1000 series is a gravity, screw, and vibration-type Jumbo Bag Filling Machine specifically designed by Wuxi Jianying for powder and granular materials. Developed based on Jianying's 33 years of expertise in packaging equipment R&D, these machines feature customized process standards that seamlessly integrate automated filling, intelligent weighing, lifting and handling, and multi-layer stacking throughout the entire workflow. They are widely applicable to material packaging, storage, and transportation across industries such as chemicals, new energy, pesticides, and metallurgy, offering excellent compatibility, stability, and durability tailored to large-scale industrial production requirements.
Technical Specifications
|
Model |
DCS-1000/1 |
DCS-1000/2 |
DCS-1000/3 |
DCS-1000/6 |
|||
|
Range |
500~1000 kg |
||||||
|
Speed |
1 0 ~ 2 0 Bag/Hour |
25 Bag/Hour |
10~ 2 0 Bag/Hour |
8 Bag/Hour |
|||
|
Accuracy |
±0.2% |
||||||
|
Power Source |
AC380/220/50Hz |
||||||
|
Air Pressure |
0.4~0.6 MPa |
||||||
|
Air Consumption |
0.3m³/min |
||||||
|
Bag |
PP woven material (PE or PE liner film lamination),four or two straps |
||||||
|
Feeding Method |
Spiral feeding |
Gravity type |
Spiral feeding |
vibration type |
|||
Feature And Application
The DCS-1000 series Jumbo Bag Filling Systems feature high weighing accuracy and stable measurement performance. Equipped with high-precision weighing sensors, they support three feeding modes: screw variable-frequency feeding, gravity direct discharge, and AC vibration feeding, making them suitable for various materials and packaging conditions. The overall measurement error is controlled within ±0.2%, meeting stringent industrial raw material measurement standards. The 1000-1 model employs a bottom-weighting design with an integrated compaction platform, specifically designed for filling powdered materials; the 1000-2 and 1000-3 models utilize a hanging top-weighting structure, tailored for packaging granular and powdered materials respectively.
The weighing sensor accurately measures material weight and, when integrated with a high-precision control system, enables real-time dynamic compensation and automatic correction, significantly enhancing production efficiency and product quality compliance rates while providing reliable data support and operational assurance for modern smart factories.
High Precision Stability: Automatic compensation for materials of varying densities ensures minimal weight fluctuations during continuous production and low raw material loss. Environmental Friendliness & Low Dust Generation: Fully enclosed filling system with optional dust removal options effectively prevents fine powder dispersion. Intelligent Traceability: Automatic recording of bag weight and shift output data, with automatic upload to workshop control systems. Durability & Maintenance: Modular design enables rapid replacement of wear-prone components; nationwide on-site after-sales service within 48 hours. Safety Enhancements: The entire unit features explosion-proof, anti-static, and corrosion-resistant stainless steel construction.
