The DCS-1000 series ton-bag packaging machine is a high-precision semi-automatic filling system specifically designed for large bags weighing 500–1000 kg, suitable for handling various materials including granules, powders, and tablets. It finds extensive application in industries such as new energy, chemicals, fertilizers, and food ingredients. Featuring a mature design, stable operation, and precise measurement capabilities, the equipment can operate independently or be integrated with conveying and palletizing systems to form fully automated packaging lines, making it the preferred choice for large-scale quantitative packaging of bulk bags in medium-to-large enterprises.
Technical Specifications
|
Model |
DCS-1000/1 |
DCS-1000/2 |
DCS-1000/3 |
DCS-1000/6 |
|||
|
Range |
500~1000 kg |
||||||
|
Speed |
1 0 ~ 2 0 Bag/Hour |
25 Bag/Hour |
10~ 2 0 Bag/Hour |
8 Bag/Hour |
|||
|
Accuracy |
±0.2% |
||||||
|
Power Source |
AC380/220/50Hz |
||||||
|
Air Pressure |
0.4~0.6 MPa |
||||||
|
Air Consumption |
0.3m³/min |
||||||
|
Bag |
PP woven material (PE or PE liner film lamination),four or two straps |
||||||
|
Feeding Method |
Spiral feeding |
Gravity type |
Spiral feeding |
vibration type |
|||
Feature And Application
* The DCS-1000 series bag packaging machines feature a modular frame design with integrated weighing capabilities, ensuring stable operation. Comprising a weighing system, feeding system, bag-clamping and sealing mechanism, and electronic control system, the equipment enables standardized packaging processes-including automatic weighing, precise material dispensing, bag fixation, and data logging-making it ideal for continuous batch production in industrial settings.
* The measurement system is accurate and reliable. It employs an independent weighing sensor structure, offering strong interference resistance, precise quantitative values, and excellent repeatability, meeting the requirements for conventional industrial metrological applications.
* The system offers extensive compatibility with a wide range of materials. Depending on material characteristics, configurations such as gravity feeding, screw feeding, or vibrating feeding can be selected to accommodate various materials including particles, conventional powders, ultrafine powders, and lumps, effectively addressing issues such as material blockage, bridging, and uneven discharge.
* The equipment features a hermetically sealed structure with excellent operational adaptability. It is standardly equipped with a bag-sealing mechanism and can be paired with dust removal interfaces to minimize dust leakage during filling, making it suitable for production workshops with stringent dust control requirements. Additionally, it incorporates lifting functions and optional material compaction features to reduce material voids and ensure uniform and full filling of bags per ton.
* The operation is simple and maintenance is easy. It features PLC-based touch control, offering intuitive parameter settings, weight adjustment, and output display. With a modular design, the equipment boasts a straightforward structure, low failure rate, and convenient daily maintenance.
* Highly versatile specifications. The equipment supports adjustable conventional tonnage bags, catering to diverse packaging requirements and suitable for both new production line integration and replacement of outdated packaging equipment.
